Core Product Summary
The Pioneer Magnetics PM3398B-6-1-3-E is a 1500 W-class AC-to-DC switching power supply from the manufacturer’s PM33xx PowerFactor series; units of this build are marked with the companion part number 80026-172-24. It accepts a wide-range AC input of 100–240 VAC at 50/60 Hz (23 A input rating) and provides a regulated 56 V DC output at 26.8 A.
As a PowerFactor-series unit, its input stage includes power-factor correction, converting the AC line into isolated, regulated DC for downstream industrial loads. The wide input range allows deployment on both 100–120 V and 200–240 V supply systems without input rewiring changes. Units in this series deliver continuous full power over a 0 °C to +50 °C ambient range and use latched overvoltage protection that clears after the AC line is removed for approximately 30 seconds and reapplied.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product type | AC-to-DC switching power supply (PFC front end) |
| Series | Pioneer Magnetics PM33xx PowerFactor series |
| Companion part number | 80026-172-24 |
| AC input | 100–240 VAC, 50/60 Hz, 23 A input rating |
| DC output | 56 V DC at 26.8 A |
| Output power | ≈1500 W |
| Input power factor | Corrected (PFC input stage) |
| Operating temperature (full power) | 0 °C to +50 °C ambient |
| Overvoltage protection | Latched shutdown at approx. 125% ±5% of nominal; clears after ~30 s line removal and reapplication |
| Output voltage adjustment | ±10% of nominal |
| Voltage stability | ±0.1% over 24 hours after warm-up |
| Safety standards (series) | UL1950, CSA 22.2 No. 950, TÜV to EN60950 |
System Compatibility & Integration Requirements
| Item / Dependency | Verified Requirement | Practical Note |
|---|---|---|
| AC input supply | 100–240 VAC, 50/60 Hz, 23 A input rating | Upstream breaker and wiring must be sized for the 23 A input class at the actual line voltage used |
| DC output | 56 V DC at 26.8 A (~1500 W) | Verify against unit nameplate; other output-voltage builds of the same model family exist |
| Build identification | Companion part number 80026-172-24 | Use the full model plus companion number when matching replacement units to an installed system |
| Installation environment | 0 °C to +50 °C ambient for full output | Include the unit’s dissipation in enclosure cooling calculations |
| Fault recovery | OVP latches until AC input is removed ~30 s and reapplied | Provide an input disconnect if rapid fault recovery is required |
| Output adjustment | ±10% trim of nominal output | Do not use trim to substitute for a different output-voltage build |
Detailed Product Overview
The PM3398B-6-1-3-E sits in the upper power range of the PM33xx PowerFactor series, Pioneer Magnetics’ line of AC-to-DC converters with power-factor-corrected input stages. With a 56 V DC, 26.8 A output, it delivers approximately 1.5 kW of continuous DC power, which places it in the class used for dense industrial load groups, auxiliary distribution rails, and telecom-style −48/56 V architectures rather than small panel supplies.
The wide-range 100–240 VAC input is the key integration benefit of this build. The same unit can be installed on a 120 VAC North American supply or a 230 VAC international supply without input hardware changes, and the PFC input stage keeps input current harmonics low on either line. The 23 A input rating defines the upstream circuit protection and wiring gauge the installation must provide.
The 56 V DC output deserves attention at specification time. Pioneer Magnetics builds the PM3398 family in multiple output-voltage configurations — 48 V builds of the same model family exist at 31 A, while this specific build provides 56 V at 26.8 A. Because the model-number suffix defines the electrical build, engineers should verify the output voltage and current against the unit nameplate before ordering, and treat the companion part number 80026-172-24 as the exact-build identifier when matching a replacement to an installed chassis.
Protection behavior follows the PowerFactor series convention: overvoltage shutdown latches, and the latch clears only after AC input is removed for roughly 30 seconds and reapplied. In racks without a remote input disconnect, this means a fault requires physical or contactor-based input interruption to recover. Thermal planning must also account for full-power delivery only up to +50 °C ambient, so cabinet ventilation should be sized for the unit’s heat dissipation alongside the loads it feeds.
PM3398B-6-1-3-E 80026-172-24
PM3398B-6-1-3-E 80026-172-24
Dimensions, Mounting & Connection Notes
- The unit is a rack/front-end format switching power supply of the PM33xx series; shipping weight for this part is listed at approximately 10 lb (≈4.5 kg).
- Input connection is to a 100–240 VAC, 50/60 Hz line; overvoltage shutdown recovery requires removing AC input for approximately 30 seconds.
- Cooling follows the PowerFactor series design (internal forced air); the mounting location must allow free airflow.
- Safety certifications for the series are referenced to UL1950, CSA 22.2 No. 950, and TÜV to EN60950.
FAQ
What is the Pioneer Magnetics PM3398B-6-1-3-E?
It is a 1500 W-class AC/DC switching power supply in the PM33xx PowerFactor series, built to accept 100–240 VAC input and deliver a 56 V DC output at 26.8 A.
What is part number 80026-172-24?
It is the companion customer/assembly part number that appears together with the PM3398B-6-1-3-E model on this build, and it identifies the exact configuration when sourcing a replacement.
What input supply does it require?
A 100–240 VAC, 50/60 Hz supply; the unit carries a 23 A input rating, so upstream protection and wiring must be sized accordingly.
What output does it provide?
A regulated 56 V DC output at 26.8 A, approximately 1500 W, with a ±10% output adjustment range and ±0.1% voltage stability over 24 hours after warm-up.
How does the overvoltage protection behave?
The OVP circuit latches a shutdown at approximately 125% ±5% of nominal output voltage and clears only after AC input is removed for about 30 seconds and reapplied.
What safety standards apply to the series?
The PM33xx series is documented to UL1950, CSA 22.2 No. 950, and TÜV to EN60950.
What temperature range does it support at full power?
Full rated output is available over an ambient range of 0 °C to +50 °C.
