Core Product Summary
The Pioneer Magnetics PM3398B-6P-1-3P-E is an AC-to-DC switching power supply from the PM33xx PowerFactor series, built in the three-phase-input (3P) configuration of the PM3398 model family; units of this build carry the companion part number 80026-172-03. It accepts a 120–240 VAC input at 50/60 Hz with a 23 A input rating.
As a PowerFactor-series unit, its input stage provides power-factor correction and converts the AC line into isolated, floating DC output for downstream industrial loads. The manufacturer documents the PM33 front-end family as available in single-phase (1P) and three-phase (3P) AC input versions, with full output power delivered over a 0 °C to +50 °C ambient range, a fully floating output, and ±0.1% output voltage stability over 24 hours after a 30-minute warm-up. Overvoltage protection on the series latches a shutdown that clears after the AC line is removed for approximately 30 seconds and reapplied.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product type | AC-to-DC switching power supply (PFC front end) |
| Series | Pioneer Magnetics PM33xx PowerFactor series |
| Input configuration | Three-phase (3P) AC input version of the PM3398 family |
| AC input | 120–240 VAC, 50/60 Hz |
| Input current rating | 23 A |
| Companion part number | 80026-172-03 |
| Input power factor | Corrected (PFC input stage) |
| Output | Isolated, fully floating DC (output voltage/current per unit nameplate) |
| Operating temperature (full power) | 0 °C to +50 °C ambient |
| Output voltage stability | ±0.1% over 24 hours after 30-minute warm-up |
| Overvoltage protection | Latched shutdown at approx. 125% ±5% of nominal; clears after ~30 s line removal and reapplication |
| Safety standards (series) | UL1950, CSA 22.2 No. 950, TÜV to EN60950 |
| Shipping weight | Approximately 11 lb (≈5 kg) |
Detailed Product Overview
The PM3398B-6P-1-3P-E is the three-phase-input member of Pioneer Magnetics’ PM3398 front-end family. The manufacturer produces the PM33 front-end line in both single-phase (1P) and three-phase (3P) AC input versions, and this model’s “-6P … -3P” suffixes place it on the three-phase side of that family tree. For engineers maintaining an installed chassis, this distinction is the single most important identification point: the three-phase input build and its single-phase sibling look similar and share the PM3398B base designation, but they are wired to different supply systems and are not interchangeable replacements for one another.
The unit accepts a 120–240 VAC line at 50/60 Hz with a 23 A input rating. On a three-phase input build, this rating defines the per-phase supply capacity, upstream protection, and input conductor sizing the installation must provide. The power-factor-corrected input stage keeps harmonic current drawn from the line low, which matters where facility power-quality specifications limit input distortion.
The output side of the PM33 front-end family is a fully floating, isolated DC rail. Because Pioneer Magnetics configures output voltage and current to the individual build, the exact output values of the -6P-1-3P-E build should be confirmed from the unit’s nameplate before a replacement is ordered — the same family includes single-phase builds documented at 56 V DC, 26.8 A (approximately 1500 W), but the output values of this specific three-phase build are defined by its own configuration record. When matching a replacement to an installed chassis, use the full model number together with the companion part number 80026-172-03.
Protection behavior follows the PowerFactor series convention: an overvoltage condition latches a shutdown at approximately 125% ±5% of nominal output, and the latch clears only after AC input is removed for about 30 seconds and reapplied. Thermal performance is specified for full output power from 0 °C to +50 °C ambient, so enclosure ventilation must account for the unit’s dissipation. Output regulation is tight — ±0.1% over 24 hours after a 30-minute warm-up — which is the stability figure that matters for loads sensitive to long-term drift.
PM3398B-6P-1-3P-E 80026-172-03
System Compatibility & Integration Requirements
| Item / Dependency | Verified Requirement | Practical Note |
|---|---|---|
| AC input supply | 120–240 VAC, 50/60 Hz, three-phase (3P) input build | Confirm the supply phases and input wiring match the three-phase build before connection |
| Input rating | 23 A | Size upstream protection and input conductors for the 23 A input class |
| Output configuration | Isolated, fully floating DC; output values per unit nameplate | Verify output voltage/current against the nameplate and configuration record before ordering |
| Build identification | Companion part number 80026-172-03 | Use full model plus companion number when matching replacements to an installed chassis |
| Installation environment | 0 °C to +50 °C ambient for full output | Include the unit’s dissipation in cabinet cooling calculations |
| Fault recovery | OVP latches until AC input is removed ~30 s and reapplied | Provide an input disconnect if rapid fault recovery is required |
| Output stability | ±0.1% over 24 h after 30-minute warm-up | Relevant when feeding loads sensitive to long-term voltage drift |
Dimensions, Mounting & Connection Notes
- The PM33 front-end family is housed in the manufacturer’s standard 5 × 5 × 11.25 inch front-end envelope.
- Shipping weight for this part is approximately 11 lb (≈5 kg).
- Input connection is to a 120–240 VAC, 50/60 Hz supply in the three-phase input configuration; overvoltage shutdown recovery requires removing AC input for approximately 30 seconds.
- The output is fully floating and galvanically isolated from the input.
- Safety certifications for the series are referenced to UL1950, CSA 22.2 No. 950, and TÜV to EN60950.
FAQ
What is the Pioneer Magnetics PM3398B-6P-1-3P-E?
It is a three-phase-input AC/DC switching power supply from the PM33xx PowerFactor series, accepting 120–240 VAC at 50/60 Hz with a 23 A input rating.
What is part number 80026-172-03?
It is the companion part number that appears with the PM3398B-6P-1-3P-E model on this build, identifying the exact configuration when sourcing a replacement.
How does the “-6P … -3P” build differ from the single-phase PM3398B?
The manufacturer builds the PM33 front-end family in single-phase (1P) and three-phase (3P) AC input versions; this model is the three-phase-input version and is wired to a different supply configuration than the single-phase sibling.
What output does it provide?
A fully floating, isolated DC output with ±0.1% voltage stability over 24 hours after warm-up; the exact output voltage and current of this build are defined by its configuration record and should be confirmed from the unit nameplate before purchase.
How does the overvoltage protection behave?
The OVP circuit latches a shutdown at approximately 125% ±5% of nominal output voltage and clears only after AC input is removed for about 30 seconds and reapplied.
What temperature range does it support at full power?
Full rated output is available over an ambient range of 0 °C to +50 °C.
What safety standards apply to the series?
The PM33xx series is documented to UL1950, CSA 22.2 No. 950, and TÜV to EN60950.
